The WARPsurf is a turning point in the world panorama of the instruments for surface analysis, because it gives in a single portable instrument the capability to perform both roughness and profilometry analysis. The brilliant 7’’ touch screen display, combined with modern user interface, allows the user to become quickly familiar with the instrument, setting easily the measure parameters, positioning on the piece and performing the analysis. The instrument is equipped with a 1GHz microprocessor that allows to have a fluid system and fast processing even with complex profiles. Extremely compact and handy, the WARPsurf allows to position easily on big pieces thanks to the integrated micrometric that covers 110 mm range. Thanks to the standard USB interface, it is possible to plug a regular USB drive to save images or PDF reports; using this interface the instrument can connect to a common desktop printer and directly print on A4. The instrument can analyze surface features along with dimensional ones, thanks to the interchangeable styluses for both roughness and profilometry. FEATURES: Measurement range : ±1500μm Resolution : 0,0001 µm - (0,1nm) Cut-off lenght : 0,08 - 0,25 - 0,8 - 2,5 - 8 mm Cut-off number : Selectable from 1 to 20 (1 to 6 for 8 mm cut-off) Traverse lenght : Up to 60 mm Pick up Inductive, it can be rotated of 90' for lateral measurements and interchangeable styluses Measurement parameters 81 roughness parameters Ra, Rq, Rt, Rz, Rp, Rv, Rc, Rsk, Rku, RSm, RΔq, RΔa, Rmax, Rδc, Rmr, Rmr(c), RPc, RLo, Rlr, Rzjis, RHSC, R3z, hp, Ep Pa, Pq, Pt, Pq, Pv, Pc, Psk, Pku, PSm, PΔq, Pδc, PPc, PLo, Plr, PHSC Wa, Wq, Wt, Wz, Wp, Wv, Wc, Wsk, Wku, WSm, WΔq, Wδc, WPc, WLo, Wlr, WHSC Rk, Rpk, Rvk, Mr1, Mr2, A1, A2, Rpk*, Rvk*, WDSm, WDc, WDt R, AR, Rx, W, Aw, Wx, Wte, Rke, Rpke, Rvke, Mr1e, Mr2e, A1e, A2e Available charts: Roughness, Waviness, Dominant waviness, Primary, Material ratio curve (bearing) and height amplitude distribution (density). Unit of measurement : Millimeters and inches User interface : Color display touchscreen TFT, 7 inches, 3 impermeable membrane switches Languages: Italian, French, Inglese, German, Spanish, Portuguese, Japanese, Chinese, Korean Memory Up to 4000 measurements for roughness – Up to 1000 for profilometry CAD : Functions to process the integrated profile, Points: carthesian – on the profile – intersection – limit – maximum - minimum Lines: best-fit – polar – interrupted - between two or more points – parallel Arcs: best-fit – interrupted - between three or more points – center and radius – tangent Dimensions: Aligned – Vertical – Horizontal – Radius – Angle – Line-point distance Advanced: Axis alignment – Z magnification Visualization: Pan – Zoom Printing : 1- Capability to print on a common USB desktop printer in A4 format (Example: HP deskjet) 2- Capability to print to PDF on a USB drive 3- Printing on a PR11 device using Bluetooth connection Equipment : WARPsurf roughness tester with SB300 magnetic probe and stylus 1-Y roughness, battery charger 110-230V, roughness specimen, plastic case, user manual Salbro Engineers represents SM Metrology Systems for their surface metrology products such as Roundness, Roughness, Contour / Profile measuring machines and accessories.
